Controller Options
155
• USB Device Server Option
• Extended USB board
1. Remove the slot cover [A].
2. Install the interface board [A] into the slot. (Knob-screw × 2 [B])
3. Make sure that the machine can recognize the option (see Check All Connections at the end of this
section).
IEEE 802.11a/g/n Interface Unit Type M19 (D3BR-01)
• Turn OFF the main power and unplug the power cord from the wall socket. If installing without
turning OFF the main power, an electric shock or a malfunction may occur.
You can only install one of the following network interfaces at a time:
• File Format Converter
To Next Page
