1.Replacement and Adjustment
19
Tray Lift Motor
1. Pull out the paper tray.
2. Remove the rear cover (Rear Cover)
3. Remove the rear stay [A]. ( × 2)
4. Remove the controller board with bracket. (Controller Board)
5. Remove the tray lift motor [A]. ( × 2, × 1)
To Next Page
