Fusing
286
2. Remove the fusing thermopile with the bracket [A]. ( × 1, × 1)
3. Remove the fusing thermopile [A]. ( × 1)
New Fusing Unit Detection Fuse
1. Remove the fusing upper cover. (Fusing Upper Cover)
