Ricoh MP C307 User Manual

3.SP Mode Tables
370
Scanner Unit/ Laser Unit
Input Check
No. Part Name SP Name SP No. Reading
0 1
2 Scanner HP sensor Scanner HP Sensor 5-803-200 Not HP HP
4 ADF set sensor Platen Cover Sensor 5-803-201 Close Open
6 Interlock switch 1 Interlock Release Detection 1 5-803-012 Door open Door close
7 Interlock switch 2 Interlock Release Detection 1 5-803-013 Door open Door close
- - LD Off Check 5-803-094 - -
Output check
No. Part Name SP Name SP No. Remark
1 Scanner lamp Scanner Lamp 5-804-202
Scanner Lamp: Color 1200 5-804-203 Not available
Scanner Lamp: Bk 5-804-204 Not available
3 Polygon motor (K/C) Polygon Motor1: Standard2 5-804-103
Polygon Moter1: Standard 5-804-104
Polygon Motor1: Low 5-804-105
5 Polygon motor (M/Y) Polygon Motor2: Standard2 5-804-107
Polygon Moter2: Standard 5-804-108
Polygon Motor2: Low 5-804-109
3, 5 Polygon motor (K/C), (M/Y) Polygon Motor1,2: Standard2 5-804-111
Polygon Moter1,2: Standard 5-804-112
Polygon Motor1,2: Low 5-804-113

Ricoh MP C307 Specifications

General

Type	Multifunction Printer
Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Maximum Paper Size	A4
Duplex Printing	Yes
Scan Resolution	600 x 600 dpi
Mobile Printing	Apple AirPrint, Google Cloud Print, Mopria
Operating Systems Supported	Windows, Mac OS, Linux
Print Speed (Black)	30 ppm
Print Speed (Color)	30 ppm
Standard Paper Capacity	350 sheets
Supported Paper Sizes	A4, A5, A6, B5, B6, Letter, Legal
Scanner Type	Flatbed with ADF (Automatic Document Feeder)
Copier Speed (Black)	30 cpm
Copier Speed (Color)	30 cpm
Copy Resolution	Up to 600 dpi
Zoom Range	25% to 400%
Connectivity	Ethernet, USB
Max. Paper Capacity	1, 350 sheets
Display	10.1-inch color touchscreen
