Machine Overview
16
Machine Overview
Overview
Callout Item Callout Item
[A] ADF [H] Bypass feed tray
[B] Scanner unit [I] Paper feed tray
[C] Paper exit unit [J] Waste toner bottle
[D] Fusing unit [K] ITB unit
[E] Duplex unit [L] PCDU
[F] Paper transfer roller [M] Toner bottle
[G] Registration roller [N] Laser unit
