Image Adjustment
197
Color Skew Adjustment
The skew adjustment of this machine should be performed manually. The adjustment procedure is as follows:
1. Open the front door [A] and then remove the paper exit tray [B]. ( x 1)
2. Close the front door and execute MUSIC (SP2-111-004).
3. Check the result for each color with the following SPs.
• SP2-117-004 (K)
• SP2-117-002 (C)
• SP2-117-001 (M)
• SP2-117-003 (Y)
• If all of the SP values are within ±5, go to Step 5.
• If any of the SP values are not within ±5, go to Step 4.
