Ricoh MP C307

Exterior Covers
202
Right Rear Cover
1. Open the right cover.
2. Remove the right rear cover [A] ( × 3)
• Remove the right rear cover while pushing it downward.
Paper Exit Tray
1. Open the front cover.
2. Remove the paper exit tray [A]. ( × 1)
Scanner Inner Cover
1. Remove the ADF and scanner unit (Scanner Unit with the ADF)
2. Remove the operation panel (Operation Panel)
