Ricoh MP C307 User Manual

Image/Paper Transfer
260
8. Pull out the ITB unit [A].
After Replacing the Image Transfer Belt Unit
Do the following after replacing the ITB unit.
1. Enter the SP mode.
2. Set SP1-001-031 (Leading Edge Registration Std. Measure: On/Off) to “1”.
3. Execute SP2-111-004 (Forced Line Position Adj. Mode d).
4. SP values from SP1-001-033 to 040 (Leading Edge Registration Offset Standard: 1 to 8) are updated by the
above steps.
5. Reset SP1-001-031 to “0”.
6. Exit from the SP mode.
7. Turn the main power off and on.
ITB Contact Motor
1. Remove the drive unit. (Drive Unit)
2. Remove the ITB contact unit [A]. ( × 3, × 1)

Ricoh MP C307 Specifications

General

Type	Multifunction Printer
Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Maximum Paper Size	A4
Duplex Printing	Yes
Scan Resolution	600 x 600 dpi
Mobile Printing	Apple AirPrint, Google Cloud Print, Mopria
Operating Systems Supported	Windows, Mac OS, Linux
Print Speed (Black)	30 ppm
Print Speed (Color)	30 ppm
Standard Paper Capacity	350 sheets
Supported Paper Sizes	A4, A5, A6, B5, B6, Letter, Legal
Scanner Type	Flatbed with ADF (Automatic Document Feeder)
Copier Speed (Black)	30 cpm
Copier Speed (Color)	30 cpm
Copy Resolution	Up to 600 dpi
Zoom Range	25% to 400%
Connectivity	Ethernet, USB
Max. Paper Capacity	1, 350 sheets
Display	10.1-inch color touchscreen
