Ricoh MP C307

3.SP Mode Tables
382
No. Part Name SP Name SP
No.
Remark
- - PP:Charge AC:M 5-
804-
061
- - PP:Charge AC:C 5-
804-
063
- - PP:Charge AC:Bk 5-
804-
065
Paper Feed Unit (Optional)
Input Check
No. Part Name SP Name SP No. Reading
0 1
2 PFU door switch 1 PFU Door Sensor 1 5-803-
062
Close Open
PFU door switch 2 PFU Door Sensor 2 5-803-
063
Close Open
3 Vertical transport sensor
1
PFU Vertical Transport Sen.
1
5-803-
060
Paper not
detected
Paper
detected
Vertical transport sensor
2
PFU Vertical Transport Sen.
2
5-803-
061
Paper not
detected
Paper
detected
Output check
No. Part Name SP Name SP No. Remark
1 Vertical transport clutch 1 PFU Vertical Transport CL1 5-804-086
Vertical transport clutch 2 PFU Vertical Transport CL2 5-804-087
4 PFU transport motor 1 PFU Transport Motor 1: High 5-804-080
PFU Transport Motor 1: Low 5-804-081
PFU transport motor 2 PFU Transport Motor 2: High 5-804-082
PFU Transport Motor 2: Low 5-804-083
5 PFU paper feed clutch 1 PFU Paper Feed CL1 5-804-084
PFU paper feed clutch 2 PFU Paper Feed CL2 5-804-085
