Ricoh MP C307

Operation Panel
206
Operation Panel
The replacement procedures for the other parts are included in the FSM for the Smart Operation Panel, because
these parts are also used with other models.
Operation Panel
1. Open the right cover.
2. Remove the front right cover [A] and hinge cover [B].
3. Remove the screws fixing the operation panel [A].
