1.Replacement and Adjustment
8
Friction Pad
1. Remove the paper feed roller. (Paper Feed Roller)
2. Remove the friction pad [A]. (Hooks × 2, × 1)
When reinstalling the friction pad:
• To prevent the friction pad from catching on the sheet [A], place the friction pad while bending the
sheet slightly outward.
