Ricoh MP C307 User Manual

1.Installation
11
4. Attach the handset bracket [A] to the upper left cover by securing two screws to the frame of the machine
through the screw holes [B]. (tapping screw)
5. Attach the cradle [A] to the bracket. (flat head screw)
6. Connect the handset cable connector to the “TEL” connector of the mainframe.
Fax Connection Unit Type M28 (D3E7-00)
Installation Procedure
This unit allows a machine without the fax unit installed (“Client-side Machine”) to send and receive faxes via a
machine with the fax unit installed (“Remote Machine”).
Requirements:
• Up to six machines can be registered as the Client-side Machines.
• Machines that have the fax unit installed cannot be used as the Client-side Machine.
• Only one machine can be registered as the Remote Machine.
• Firmware for this unit: “aics” (software number: D3A7759)
• Remote Fax transmissions are possible on a G3 line.
• The remote fax function does not support User Code Authentication. Disable the User Code Authentication
on the Remote machine.
• Use this function to check the contents of a file that is stored in memory and not yet sent. Also, use this

Ricoh MP C307 Specifications

General

Type	Multifunction Printer
Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Maximum Paper Size	A4
Duplex Printing	Yes
Scan Resolution	600 x 600 dpi
Mobile Printing	Apple AirPrint, Google Cloud Print, Mopria
Operating Systems Supported	Windows, Mac OS, Linux
Print Speed (Black)	30 ppm
Print Speed (Color)	30 ppm
Standard Paper Capacity	350 sheets
Supported Paper Sizes	A4, A5, A6, B5, B6, Letter, Legal
Scanner Type	Flatbed with ADF (Automatic Document Feeder)
Copier Speed (Black)	30 cpm
Copier Speed (Color)	30 cpm
Copy Resolution	Up to 600 dpi
Zoom Range	25% to 400%
Connectivity	Ethernet, USB
Max. Paper Capacity	1, 350 sheets
Display	10.1-inch color touchscreen
