Ricoh MP C307

Drive
272
Paper Transport Motor
1. Remove the fusing motor. (Fusing Motor)
2. Remove the fusing motor bracket [A]. ( × 2)
3. Remove the harness guide [A]. ( × 3, × 14)
• There are connectors behind the harness guide. Remove the guide carefully.
