Paper Feed
290
4. Remove the paper feed roller. (Hook × 1)
5. Remove the friction pad [A]. (Hooks × 2)
Registration Sensor, Paper Feed Sensor
1. Open the right door.
• If you find paper dust in the registration section when you open the duplex unit, remove the dust.
Otherwise, the dust can cause lines on the image.
