Ricoh MP C307

1.Replacement and Adjustment
10
4. Remove the grounding plate [A] and sensor bracket [B], and then loosen the discharge plate [C]. ( × 4,
× 2, × 1)
5. Remove the shaft [A] with the vertical transport roller ( × 2, bearings × 2).
