Controller Options
164
10. Insert the Ethernet cable [A] into the Ethernet port on this option.
11. Insert the other end of the Ethernet cable to a PC for network setting.
12. Plug the power cord and turn ON the power.
• Do not unplug the USB cable while the machine is recognizing this option. It may take between
30 seconds to 1 minute to finish recognizing it (the LEDs on the Ethernet port of this option light
up after recognizing this option; see below). If unplugged, connect the cable again.
13. Make sure that the machine recognizes this option correctly by doing one of the following:
1. Access the option’s IP address from a web browser.
2. Ping the option’s IP address from a command prompt on a Windows PC in the same network as the
mainframe.
If the IP address cannot be found (DHCP server), use the MAC address. This is the number printed on
the seal attached to the printed circuit board for the USB server.
3. Use “RX” + the option’s MAC address and access a web browser.
Example: http://RX0080926A3264
