Ricoh MP C307

ADF
217
3. Slide the shaft [A], and then remove the pickup roller [B].
Replacing the Feed Roller
1. Remove the original feed unit. (Original Feed Unit)
2. Remove the clip [A].
3. Slide the shaft [A], and then remove the pin [B].
