Ricoh MP C307 User Manual

Mainframe Installation
49
If there is already a machine with one or more optional paper feed unit(s), be sure to disconnect the
machine and paper feed unit(s), and lift them up separately when moving/transporting. Otherwise, the
handle of the paper feed unit will break due to the machine’s weight, and it can cause an injury.
The following should be done before transporting the machine.
1. Remove the paper tray and waste toner bottle, and then move the ITB contact lever [A] down to the
shipping position. This moves the ITB away from the PCDU (K).
2. Hold the lever [A] in this position with tape.
3. Do SP4-806-001 to move the scanner carriage from the home position. This prevents dust from falling into
the machine during transportation.
4. Remove the toner bottles. This prevents toner flow into the toner supply tube, which is caused by vibration
during transport. This can also cause the tube to be clogged with toner.
5. Make sure that there is no paper left in the paper trays. Then fix down the bottom plates with a sheet of
paper and tape.
6. Attach securing tape to stop the waste toner bottle from coming out.
7. Do one of the following:
• Attach shipping tape to the covers and doors.
• Shrink-wrap the machine tightly.

Ricoh MP C307 Specifications

General

Type	Multifunction Printer
Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Maximum Paper Size	A4
Duplex Printing	Yes
Scan Resolution	600 x 600 dpi
Mobile Printing	Apple AirPrint, Google Cloud Print, Mopria
Operating Systems Supported	Windows, Mac OS, Linux
Print Speed (Black)	30 ppm
Print Speed (Color)	30 ppm
Standard Paper Capacity	350 sheets
Supported Paper Sizes	A4, A5, A6, B5, B6, Letter, Legal
Scanner Type	Flatbed with ADF (Automatic Document Feeder)
Copier Speed (Black)	30 cpm
Copier Speed (Color)	30 cpm
Copy Resolution	Up to 600 dpi
Zoom Range	25% to 400%
Connectivity	Ethernet, USB
Max. Paper Capacity	1, 350 sheets
Display	10.1-inch color touchscreen
