Ricoh MP C307 User Manual

Paper Feed Unit PB1080/PB1080TE (Optional)
604
Tray Lifting up Mechanism
Callout Item Callout Item
[A] Tray Bottom Plate Pressure Lever [D] Tray Bottom Plate HP Sensor
[B] Tray Bottom Plate Lift Sensor [E] Tray Bottom Plate Lift Lever
[C] Lift Lever Encoder [F] Tray Bottom Plate
The pressure of the tray bottom plate [F] can be adjusted depending on the amount of paper remaining.
The pulses from the lift lever encoder [C] are detected by the tray bottom plate lift sensor [B]. The tray lift
motor is controlled based on the pulses from the encoder.
Preventing Theft of Paper (Only PB1080TE)
Paper Feed Unit PB1080TE is the optional PFU which can be locked with a key.
The key cylinder [A] is mounted on the front cover of the tray for preventing theft of paper. When the tray is
locked with a key, it cannot be pulled out. Even if the machine body is unloaded from the PFU, taking out paper
is impossible, because the plate [B] is fixed on top of the PFU.
In addition, in this model, the ribs [C] are added to the vertical transport unit. The ribs prevent from inserting
fingers into the tray and rotating the feed roller with hands.

Ricoh MP C307 Specifications

General

Type	Multifunction Printer
Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Maximum Paper Size	A4
Duplex Printing	Yes
Scan Resolution	600 x 600 dpi
Mobile Printing	Apple AirPrint, Google Cloud Print, Mopria
Operating Systems Supported	Windows, Mac OS, Linux
Print Speed (Black)	30 ppm
Print Speed (Color)	30 ppm
Standard Paper Capacity	350 sheets
Supported Paper Sizes	A4, A5, A6, B5, B6, Letter, Legal
Scanner Type	Flatbed with ADF (Automatic Document Feeder)
Copier Speed (Black)	30 cpm
Copier Speed (Color)	30 cpm
Copy Resolution	Up to 600 dpi
Zoom Range	25% to 400%
Connectivity	Ethernet, USB
Max. Paper Capacity	1, 350 sheets
Display	10.1-inch color touchscreen
