1 Bin Tray BN1030 (Optional)
607
Paper Exit from 1-Bin Tray Unit
Callout Item Callout Item
[A] 1-Bin Tray Paper Remaining Sensor [C] 1-Bin Tray Exit Sensor
[B] LED Board
The paper from the paper exit section is transported to the 1-bin unit.
This uses the same transport path as usual even if duplex is used.
The1-bin tray paper remaining sensor [A] detects the fed out paper, and the LED [B] blinks to inform users that
there is paper on the 1-bin tray after the end of the job.
The 1-bin tray exit sensor [C] detects paper jams in the 1-bin tray.
