Ricoh MP C307

1-Bin Tray BN1030 (D574-58)
65
4. Remove the front right cover [A] and the hinge cover [B].
5. Remove the scanner rear cover [A] and scanner rear small cover [B].
6. Release two screws and three tabs for attaching the relay board [A] and FFC, to release the FFC.
