Internal Finisher Installation
1. Attach the finisher right cover [A] to the guide rail [B] ( x 1; M3x6).
2. Install the internal finisher [A].
• Align the wheel [B] at the front of the internal finisher with the groove on the guide rail when
installing the internal finisher
3. Insert the rear rail [C] into the left frame of the main machine ( x 1: M4x6).
2. Installation
102
