No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
636 D
OSM User Code File Error
The correct "usercode" file could not be found in the root folder of the SD card
because the file is not present, or the existing file is corrupted or the wrong type
file.
• Make sure the eccm.mod file is in the root folder of the SD card.
Note: The usercode files are created with the User Setting Tool "IDissuer.exe".
Check the eccm.mod file is in the root folder of the SD card.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
641 D
Engine-Controller Communication Error: Non-Response
There was no response to a frame sent from the controller board to the engine.
Turn the machine power off/on.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
650 CTL Communication error of the remote service modem (Cumin-M)
-001 -
Authentication error
The authentication for the Cumin-M failed at dial up connection.
• Incorrect SP settings
• Disconnected telephone line
•
Disconnected modem board
Check and set the correct user name (SP5816-156) and password
(SP5816-157).
-004 -
Incorrect modem setting
Dial up fails due to the incorrect modem setting.
Same as -001
Check and set the correct AT command (SP5819-160).
Service Call Conditions
71
3
