1 MainMotor:150 [–4 to 4 / 0 / 0.01 %/step]
2 MainMotor:122 [–4 to 4 / 0 / 0.01 %/step]
10 Duplex:Low [–4 to 4 / 0 / 0.01 %/step]
11 Duplex:High [–4 to 4 / 0 / 0.01 %/step]
24 Reverse:Low [–4 to 4 / 0 / 0.01 %/step]
29 Reverse:High [–4 to 4 / 0 / 0.01 %/step]
1903*
Feed Cl Re-energize
Adjusts the paper feed amount allowed by the clutch after correcting the skew at
registration. When paper jams occur after restarting paper feed after registration,
increase the value to help the registration roller feed the paper.
1 By-pass Feed
[0 to 10 / 5 / 1 mm/step]2 Tray 1 Feed
3 Other Trays
1907* Paper Feed Timing Adj.
1 Feed Solenoid ON
[-10 to 10 / 0 / 1mm /step]5 Inverter Stop Position
15 Re-Feed Stop Position
20 Bank1: Feed Solenoid ON: Plain The feed solenoid turns on A mm before
the pick-up roller feed out the trailing
edge of the paper.
A=(Original length – 80) x B / 100
B=setting value
[35 to 85 / 60 / 5% /step]
21 Bank1: Feed Solenoid ON: Middle Thick
4. Appendix: Service Program Mode Tables
134
