22 Bank1: Feed Solenoid ON: Thick 1
The feed solenoid turns on A mm before
the pick-up roller feed out the trailing
edge of the paper.
A=(Original length – 80) x B / 100
B=setting value
[35 to 85 / 35 / 5% /step]
23 Bank2: Feed Solenoid ON: Plain The feed solenoid turns on A mm before
the pick-up roller feed out the trailing
edge of the paper.
A=(Original length – 80) x B / 100
B=setting value
[35 to 85 / 60 / 5% /step]
24 Bank2: Feed Solenoid ON: Middle Thick
25 Bank2: Feed Solenoid ON: Thick 1
The feed solenoid turns on A mm before
the pick-up roller feed out the trailing
edge of the paper.
A=(Original length – 80) x B / 100
B=setting value
[35 to 85 / 35 / 5% /step]
26 Bank1: Feed Clutch OFF: Plain
The feed solenoid turns off A mm after the
pick-up roller feed out the trailing edge of
the paper.
A=4 + B
B=setting value
[-10 to 10 / 0 / 1mm /step]
27 Bank1: Feed Clutch OFF: Middle Thick
28 Bank1: Feed Clutch OFF: Thick 1
29 Bank2: Feed Clutch OFF: Plain
30 Bank2: Feed Clutch OFF: Middle Thick
31 Bank2: Feed Clutch OFF: Thick 1
32 Bank Feed Wait Position
Stop and hold the paper A mm after the
leading edge of the paper activates the
vertical transport sensor.
A=setting value
[-20 to 20 / 0 / 1mm /step]
1908* Paper Feed Timing Adj.
System SP Tables-1
135
4
