Rigol DS2000E Series Programming Guide

RIGOL 2 Command System
2-118 DS2000E Programming Guide
:FUNCtion:WANalyze:STEMplate
Syntax
:FUNCtion:WANalyze:STEMplate
Description
Set the waveform analysis template when the analysis mode is trace.
Explanation
After the analysis starts, the oscilloscope compares each frame of data measured with the data in the
template to determine whether error frame exists according to the threshold set.
:FUNCtion:WANalyze:CMASk
Syntax
:FUNCtion:WANalyze:CMASk
Description
Apply the mask currently created.
Explanation
 For the setting of the horizontal adjustment parameter, refer to
the
:FUNCtion:WANalyze:SETup:XMASk command.
 For the setting of the vertical adjustment parameter, refer to the
:FUNCtion:WANalyze:SETup:YMASk
command.
:FUNCtion:WANalyze:STARt
Syntax
:FUNCtion:WANalyze:STARt
Description
Start the waveform analysis.
Explanation
During the analysis process, the progress bar is displayed, and the parameters cannot be modified. After
the analysis finishes, the analysis results of "Error Frames", "Current Error", and "CurFrame Diff" are
displayed; at the same time, the first error frame is located.
