Rigol DS2000E Series Programming Guide

RIGOL 2 Command System
2-300 DS2000E Programming Guide
:TRIGger:SPI:DATA
Syntax
:TRIGger:SPI:DATA <data>
:TRIGger:SPI:DATA?
Description
Set or query the data value of SPI trigger.
Parameter
Name Type Range Default
<data> Integer 0 to 2
n
-1 0
Note: In the expression 2
n
-1, n is the current data bits (refer to the :TRIGger:SPI:WIDTh command).
Return Format
The query returns the data value of SPI trigger in integer.
:TRIGger:SPI:SCL
:TRIGger:SPI:SDA
Syntax
:TRIGger:SPI:SCL <scl>
:TRIGger:SPI:SCL?
:TRIGger:SPI:SDA <sda>
:TRIGger:SPI:SDA?
Description
Set or query the clock channel source of SPI trigger.
Set or query the data channel source of SPI trigger.
Parameter
Name Type Range Default
<scl> Discrete {CHANnel1|CHANnel2} CHANnel1
<sda> Discrete {CHANnel1|CHANnel2} CHANnel2
Return Format
The query returns CHAN1 or CHAN2.
