Rigol DS2000E Series Programming Guide

RIGOL 2 Command System
2-314 DS2000E Programming Guide
:TRIGger:WINDows:POSition
Syntax
:TRIGger:WINDows:POSition <pos>
:TRIGger: WINDows:POSition?
Description
Set or query the trigger position of windows trigger.
Parameter
Name Type Range Default
<type> Discrete {EXIT|ENTER|TIMe} ENTER
Explanation
 EXIT: trigger when the input signal exits the specified trigger level range.
 ENTER: trigger when the trigger signal enters the specified trigger level range.
 TIMe: trigger when the accumulated hold time after entering the specified trigger level range is
greater than the windows time. The range is from 16ns to 4s and the default is 1.00us.
Return Format
The query returns EXIT, ENTER, or TIM.
:TRIGger:WINDows:TIMe
Syntax
:TRIGger:WINDows:TIMe <NR3>
:TRIGger: WINDows:TIMe?
Description
Set or query the windows time of windows trigger.
Parameter
Name Type Range Default
<NR3> Real 16ns to 4s 1us
Explanation
This command is only available when the trigger position of windows trigger (refer to
the
:TRIGger:WINDows:POSition command) is set to TIMe.
Return Format
The query returns the windows time in scientific notation.
