Rigol DS2000E Series Programming Guide

RIGOL 2 Command System
2-46 DS2000E Programming Guide
:CALCulate:ADD:INVert
Syntax
:CALCulate:ADD:INVert <bool>
:CALCulate:ADD:INVert?
Description
Enable or disable the inverted display of the addition operation result; or query the current status of the
inverted display of the addition operation result.
Parameter
Name Type Range Default
<bool> Bool {{1|ON}|{0|OFF}} 0|OFF
Return Format
The query returns 1 or 0.
:CALCulate:ADD:VSCale
Syntax
:CALCulate:ADD:VSCale <scale>
:CALCulate:ADD:VSCale?
Description
Set or query the vertical scale of the addition operation result. The unit is related to the amplitude unit of
the signal source channel.
Parameter
Name Type Range Default
<scale> Real
The default range is from 0.02V to 500V.
The actual range is related to the vertical scale of the signal
source channel.
2V
Note: For the channel vertical scale, refer to the :CHANnel<n>:SCALe command.
Return Format
The query returns the vertical scale of the addition operation result in scientific notation.

Rigol DS2000E Series Specifications

General

Bandwidth	70 MHz to 200 MHz
Channels	2 or 4
Vertical Sensitivity	1 mV/div to 10 V/div
Vertical Resolution	8-bit
Timebase Range	2 ns/div to 50 s/div
Memory Depth	14 Mpts
Input Impedance	1 MΩ ± 1%
Trigger Modes	Edge, Pulse, Video
Waveform Capture Rate	50, 000 wfm/s
Interfaces	USB, LAN
Power Supply	100-240 VAC
Display	8-inch WVGA (800x480) LCD
