Rigol DS2000E Series Programming Guide

2 Command System RIGOL
DS2000E Programming Guide
2-71
:CALCulate:ADVanced:VARiable1
:CALCulate:ADVanced:VARiable2
Syntax
:CALCulate:ADVanced:VARiable1 <numeric_value>
:CALCulate:ADVanced:VARiable1?
:CALCulate:ADVanced:VARiable2 <numeric_value>
:CALCulate:ADVanced:VARiable2?
Description
Set or query the variable1 in the advanced operation expression.
Set or query the variable2 in the advanced operation expression.
Parameter
Name Type Range Default
<numeric_value> Real Refer to Explanation 0
Explanation
 The format of <numeric_value> is AeB. The range of A (mantissa) is from -9.9999 to 9.9999 (the
minimum step is 0.0001; namely the number can contain at most 4 decimal places). B (exponent, its
base is 10) is an integer from -9 to 9. For example, 1.2037e5 denotes setting the viariable to
1.2037×10
5
. <numeric_value> can also be expressed in decimal format; its range corresponds to
that in AeB format.
 This command sets the value of variable1 or variable2 which might be used in
the
:CALCulate:ADVanced:EXPRession command.
Return Format
The query returns the value of variable1 or variable2 in the advanced operation expression in scientific
notation.

Rigol DS2000E Series Specifications

General

Bandwidth	70 MHz to 200 MHz
Channels	2 or 4
Vertical Sensitivity	1 mV/div to 10 V/div
Vertical Resolution	8-bit
Timebase Range	2 ns/div to 50 s/div
Memory Depth	14 Mpts
Input Impedance	1 MΩ ± 1%
Trigger Modes	Edge, Pulse, Video
Waveform Capture Rate	50, 000 wfm/s
Interfaces	USB, LAN
Power Supply	100-240 VAC
Display	8-inch WVGA (800x480) LCD
