Originals
Size and Weight Restrictions
Using the Stage Glass
The Stage Glass can be used to print from bound originals or sheet originals.
Usable originals are as follows:
Size: Max. A3 (297 mm × 420 mm) or Ledger (11" × 17") Weight: Max. 22-lb (10 kg)
Min. 2" × 3
1
⁄2" (50 mm × 90 mm)
The margins indicated on the figure to the right are required for the original.
Reduce the original if necessary to fit it inside these margins.
NOTE
• If an original is wrinkled, curled, or creased, flatten it thoroughly so that the
originals can be pressed directly onto the Stage Glass during processing.
• If correction fluid or glue is used on an original, thoroughly dry it before you
place the original on the Stage Glass.
Using the Optional ADF
You can use the optional ADF (Automatic Document Feeder) to feed automatically up
to 50 original sheets.
Usable original sheets are as follows:
Size: Max.
A3 (297 mm × 420 mm) or Ledger (11" × 17") Weight: Max. 28-lb bond (110 g/m
2
)
Min. 4" × 5
7
⁄8" (100 mm × 148 mm) Min. 15-lb bond (50 g/m
2
)
NOTE
Use the Stage Glass when printing the following originals:
• Patched or worn originals
• Wrinkled, curled, folded, or torn originals
• Transparent originals (such as tracing paper or OHP transparencies)
• Chemically treated originals (such as thermal or carbon paper)
• Originals with correction fluid or glue
• Extremely thin originals (less than 15-lb bond (50 g/m
2
))
• Extremely thick originals (greater than 28-lb bond (110 g/m
2
))
• Heavy drawing paper
• Bound originals
• Originals with staples or clips
Feed
direction
5 mm 2 mm
3 mm
3 mm
