6. OPERATIONS OF THE BASIC FUNCTIONS
IMR02C15-E4
6-33
Engineering mode:
Function block 00 (F00)
Function block 01 (F01)
Function block 03 (F03)
Function block 04 (F04)
Function block 06 (F06)
Function block 07 (F07)
Function block 08 (F08)
Function block 09 (F09)
Function block 10 (F10)
Cannot be set to no display.
Function block 21 (F21)
Function block 23 (F23)
Function block 30 (F30)
Function block 33 (F33)
Function block 41 (F41)
Function block 42 (F42)
Function block 43 (F43)
Function block 44 (F44)
Function block 45 (F45)
Function block 51 (F51)
Function block 52 (F52)
Function block 60 (F60)
Function block 70 (F70)
Function block 91 (F91)
Normally, these are set to no display.
These can be displayed by setting “128” in Mode selection (no display)
(MoDE) of Function block 00 (F00) of Engineering mode. Note that display/no
display selection by Function block (F) is not possible.
Parameters in the Engineering mode (F21 to F70) should be set
according to the application before setting any parameter related to
operation. Once the parameters in the Engineering mode are set
correctly, no further changes need to be made to parameters for the
same application under normal conditions. If they are changed
unnecessarily, it may result in malfunction or failure of the
instrument. RKC will not bear any responsibility for malfunction or
failure as a result of improper changes in the Engineering mode.
Some parameters may not be displayed depending on product specifications.
!
