RKC INSTRUMENT RB Series User Manual

3. WIRING
IMR02C15-E4
3-14
 Communication [optional]
• With Communication function, terminals 13 through 15 (RB700: terminals 25 through 27) are
allocated to Communication.
For the wiring, refer to Communication Quick Instruction Manual (IMR02C41-E) or
Communication Instruction Manual (IMR02C16-E).
T/R (A)
T/R (B)
SG
14
13
15
RS-485
RB100/400/500/900
RB700
T/R (A)
T/R (B)
SG
26
25
27
RS-485
