RKC INSTRUMENT RB Series User Manual

8. PARAMETER DESCRIPTION
IMR02C15-E4
8-97
Dummy
F30
STOP display selection
STOP message for control STOP mode can be displayed either on the upper
display or the lower display. SPCH is to select the display to show the STOP
message.
Data range Factory set value
0: STOP on PV display + STOP lamp (green)
lights
1: STOP on SV display + STOP lamp (green)
lights
2: STOP lamp (green) lights
1
 Description of function
Parameter display in the STOP mode (control STOP)
• When the STOP display selection is set to “0: STOP on PV display + STOP lamp (green)
lights”
• When the STOP display selection is set to “1: STOP on SV display + STOP lamp (green)
lights”
• When the STOP display selection is set to “2: STOP lamp (green) lights”
SPCH
STOP
$
200
SV1
PV/SV monitor
OUT1 OUT2AT DO1 DO2
MAN STOP DO3 DO4
Displays the STOP
on the PV display.
Displays the Set value (SV) on the SV display.
STOP lamp lights
28
$
STOP
SV1
PV/SV monitor
OUT1 OUT2AT DO1 DO2
MAN STOP DO3 DO4
Displays the Measured value (PV)
on the PV display.
Displays the STOP on the SV display.
STOP lamp lights
28
$
200
SV1
PV/SV monitor
OUT1 OUT2AT DO1 DO2
MAN DO3 DO4
Displays the Measured value (PV)
on the PV display.
Displays the Set value (SV) on the SV display.
STOP lamp lights
