C. Current Transformer (CT) Dimensions
 CTL-6-P-N (For 0 to 30 A)
(Unit: mm)
Approx. 130 25
14.5
21
φ
5.8
15
10
 CTL-12-S56-10L-N (For 0 to 100 A)
(Unit: mm)
15
7.5
30 40
M3 Depth 4
Approx. 100 40
30
φ
12
