8. PARAMETER DESCRIPTION
IMR02C15-E4
8-134
Dummy
F60
Communication speed
Communication speed is to set Communication speed for Communication
function.
Data range Factory set value
0: 2400 bps
1: 4800 bps
2: 9600 bps
3: 19200 bps
3
For the Communication function, refer to the Communication
Instruction Manual (IMR02C16-E).
F60
Data bit configuration
This item is Data bit configuration of Communication function.
Data bit configuration
Set value
Data Parity Stop
Modbus
Communi-
cation
RKC
Communi-
cation
0 8 Without 1
1 8 Without 2
2 8 Even 1 Selectable
3 8 Even 2
4 8 Odd 1
5 8 Odd 2 Selectable
6 7 Without 1
7 7 Without 2
8 7 Even 1 Not
9 7 Even 2 selectable
10 7 Odd 1
11 7 Odd 2
Factory set value: 0 (Data bit: 8, Parity bit: Without, Stop bit: 1)
For the Communication function, refer to the Communication
Instruction Manual (IMR02C16-E).
bPS
bIT
