RKC INSTRUMENT RB Series User Manual

8. PARAMETER DESCRIPTION
IMR02C15-E4
8-53
Item Default value Item Default value
Event 1 differential gap
Event 1 timer
Event 2 differential gap
Event 2 timer
Event 3 differential gap
Event 3 timer
Event 4 differential gap
TC/RTD inputs: 2 (2.0) °C [°F]
Voltage (V)/Current (I) inputs: 0.2
Event 4 timer
0 seconds
Event 1 hold action
Event 2 hold action
Transmission output
scale high
High-limit value of input span
Event 3 hold action
Event 4 hold action
0
Transmission output
scale low
Low-limit value of input span
 When Transmission output type (Ao) is changed
The following parameter will be changed to factory default values according to the new setting.
Item Default value Item Default value
Transmission output
scale high
High-limit value of input span Transmission output
scale low
Low-limit value of input span
 When Event 1 type (ES1) is changed
The following parameter will be changed to factory default values according to the new setting.
Item Default value Item Default value
Event 1 set value (EV1) TC/RTD inputs: 50 (50.0) °C [°F]
Voltage (V)/Current (I) inputs: 5.0
Event 1 differential gap TC/RTD inputs: 2 (2.0) °C [°F]
Voltage (V)/Current (I) inputs: 0.2
Event 1 set value (EV1)
[high]
TC/RTD inputs: 50 (50.0) °C [°F]
Voltage (V)/Current (I) inputs: 5.0
Event 1 hold action 0
Event 1 set value (EV1’)
[low]
TC/RTD inputs: −50 (−50.0) °C [°F]
Voltage (V)/Current (I) inputs: −5.0
Event 1 timer 0 seconds
 When Event 2 type (ES2) is changed
The following parameter will be changed to factory default values according to the new setting.
Item Default value Item Default value
Event 2 set value (EV2) TC/RTD inputs: 50 (50.0) °C [°F]
Voltage (V)/Current (I) inputs: 5.0
Event 2 differential gap TC/RTD inputs: 2 (2.0) °C [°F]
Voltage (V)/Current (I) inputs: 0.2
Event 2 set value (EV2)
[high]
TC/RTD inputs: 50 (50.0) °C [°F]
Voltage (V)/Current (I) inputs: 5.0
Event 2 hold action 0
Event 2 set value (EV2’)
[low]
TC/RTD inputs: −50 (−50.0) °C [°F]
Voltage (V)/Current (I) inputs: −5.0
Event 2 timer 0 seconds
 When Event 3 type (ES3) is changed
The following parameter will be changed to factory default values according to the new setting.
Item Default value Item Default value
Event 3 set value (EV3) TC/RTD inputs: 50 (50.0) °C [°F]
Voltage (V)/Current (I) inputs: 5.0
Event 3 differential gap TC/RTD inputs: 2 (2.0) °C [°F]
Voltage (V)/Current (I) inputs: 0.2
Event 3 set value
(EV3) [high]
TC/RTD inputs: 50 (50.0) °C [°F]
Voltage (V)/Current (I) inputs: 5.0
Event 3 hold action 0
Event 3 set value (EV3’)
[low]
TC/RTD inputs: −50 (−50.0) °C [°F]
Voltage (V)/Current (I) inputs: −5.0
Event 3 timer 0 seconds
 When Event 4 type (ES4) is changed
The following parameter will be changed to factory default values according to the new setting.
Item Default value Item Default value
Event 4 set value (EV4) TC/RTD inputs: 50 (50.0) °C [°F]
Voltage (V)/Current (I) inputs: 5.0
Event 4 differential gap TC/RTD inputs: 2 (2.0) °C [°F]
Voltage (V)/Current (I) inputs: 0.2
Event 4 set value (EV4)
[high]
TC/RTD inputs: 50 (50.0) °C [°F]
Voltage (V)/Current (I) inputs: 5.0
Event 4 hold action 0
Event 4 set value (EV4’)
[low]
TC/RTD inputs: −50 (−50.0) °C [°F]
Voltage (V)/Current (I) inputs: −5.0
Event 4 timer 0 seconds
