RKC INSTRUMENT RB Series User Manual

8. PARAMETER DESCRIPTION
IMR02C15-E4
8-98
Dummy
Function block 33 (F33)
This is the first parameter symbol of Function block 33 (F33).
Transmission output (optional) function must be specified.
F33
Transmission output type
Use to select the Transmission output type.
Data range Factory set value
0: Manipulated output value (MV1)
1: Measured value (PV)
2: Set value (SV)
1
Related parameters
Engineering mode:
• Output status at STOP mode (P. 8-96)
• Transmission output scale high (P. 8-99)
• Transmission output scale low (P. 8-99)
• AO full scale adjustment value (P. 8-100)
• AO zero point adjustment value (P. 8-100)
 Description of function
The Transmission output function (optional) is outputting the state of Measured value (PV), Set value
(SV) or Manipulated output value (MV1) as a voltage or current signal. It is possible to record the
state of Measured value (PV) or Set value (SV) when connected to a recorder.
Output types of transmission output:
Voltage output 0 to 5 V DC, 0 to 10 V DC, 1 to 5 V DC
Current output 0 to 20 mA DC, 4 to 20 mA DC
For the setting example of Transmission output, refer to 7.3 Transmission Output Function
(P. 7-12).
F33.
AO
