RKC INSTRUMENT RB Series - Event 1 Type; Event 2 Type

8. PARAMETER DESCRIPTION
IMR02C15-E4 8-101
Dummy
Function block 41 (F41)
Function block 42 (F42)
Function block 43 (F43)
Function block 44 (F44)
This is the first parameter symbol of Function block 41 (F41).
This is the first parameter symbol of Function block 42 (F42).
This is the first parameter symbol of Function block 43 (F43).
This is the first parameter symbol of Function block 44 (F44).
F41
Event 1 type
F42
Event 2 type
F43
Event 3 type
F44
Event 4 type
Use to select a action type of the Event 1.
Use to select a action type of the Event 2.
Use to select a action type of the Event 3.
Use to select a action type of the Event 4.
Data range Factory set value
0 to 23
Refer to Event type (P. 8-102).
0
If the Event type is specified
by the initial setting code
when ordering, that Event
type will be the factory set
value.
F41.
E51
F42.
F43.
F44.
E52
E53
E54
