8. PARAMETER DESCRIPTION
IMR02C15-E4
8-13
8.4.2 Parameter setting item
Set value 1 (SV1)
Set value 2 (SV2)
Set value 3 (SV3)
Set value 4 (SV4)
Factory default setting:
The screen is not displayed.
Set value (SV) for control can be set.
Up to four Set values (SV) can be stored. The (SV) selection function (SV step
function) can be used to change individual values. The Timer function can also
be used to make (SV) changes.
Data range Factory set value
Setting limiter low to Setting limiter high 0 (0.0)
Set value (SV) is not displayed as the default when the block selection at
F01 [S.F01] (P. 8-62) is set to “1: No display” in the Engineering mode.
To show the parameter, set the value to “0: Display.”
Set value (SV) set at SV selection shows up in the SV setting mode.
For the operating procedure of the SV selection function, refer to 7.1 SV
Selection Function (SV Step Function) (P. 7-2).
For the operating procedure of the Timer function, refer to 7.2 Timer
Function (P. 7-5).
Related parameters
Parameter setting mode:
• SV selection (P. 8-14)
• Timer 1, Timer 2, Timer 3, Timer 4 (P. 8-15)
• Timer function (P. 8-16)
• Repeat execution times (P. 8-17)
• Setting change rate limiter (up), Setting change rate limiter (down) (P. 8-18)
Engineering mode:
• Set value 1 (SV1), Set value 2 (SV2), Set value 3 (SV3), Set value 4 (SV4)
(P. 8-60)
• Setting limiter high, Setting limiter low (P. 8-93)
SV1
SV2
SV3
SV4
