8. PARAMETER DESCRIPTION
IMR02C15-E4
8-8
ダミー
Measured value (PV)/Manipulated output value (MV)
PV display:
The Measured value (PV) is displayed.
SV display:
When the operation mode is the Manual (MAN) mode, the Manipulated
output value (MV) can be set.
Display or Data range
Factory
set value
PID control:
Output limiter low to Output limiter high
0.0
Heat/Cool PID control:
−Cool-side output limiter (high) to
+Heat-side output limiter (high)
0.0
The Manipulated output value (MV) on the PV/SV display link to the
Manipulated output values (MV) in the Parameter setting mode and
Engineering mode. Manipulated output value (MV) in the Parameter
setting mode and the Engineering mode are automatically changed to the
same values in accordance with the change of Manipulated output value
(MV) set on the PV/SV display. Manipulated output values (MV) is not
displayed as the default value of the block selection at F10 (P. 8-87)
when set to “1: No display” in the Engineering mode. To show the
parameter, set the value to “0: Display.”
For details on changing the Manipulated output value (MV),
refer to 6.5 Auto/Manual Transfer (P. 6-20).
Related parameters
Parameter setting mode:
• Manual manipulated output value (MV) (P. 8-42)
Engineering mode:
• Manual manipulated output value (MV) (P. 8-86)
SV display
PV display
28
00
0
. 0
MAN mode lamp lights
28
%
000
.
0
SV1
OUT1
OUT
2
A
T
DO1 DO
2
MAN
STOP
DO3
DO4
Unit (%) of Manipulated output value (MV)
