10. SPECIFICATIONS
IMR02C15-E4
10-12
îš„ SV selection function
Number of SV: 4 points
Setting method: Front keys
Communication
Digital input (DI)
Attention must be paid to the number of EEPROM writes. (P. 10-18)
Setting range: 1 to 4
îš„ Timer function
Timer setting: 00 minutes 01 seconds to 99 minutes 59 seconds or
00 hours 01 minutes to 99 hours 59 minutes
Timer time unit: Min.: sec. or Hour: min.
Function selection: Timer function 1, Timer function 2, Timer function 3, Timer function 4
Repeat execution times: 0 to 9999 (9999: Infinite times)
Effective when Timer function 3 or 4 is selected.
• When power failure occurs during the process of timer time, it restarts from 0:00.
• The timer time restarts from 0:00 when Timer functions are switched.
îš„ Operation mode
Auto mode: Optimum PID values are automatically measured, computed and set.
Manual mode: Optimum PID values are tuned manually by front keys.
Control stop (STOP mode)
: Time-proportional control output: OFF (Contact open) *
Control output (continuous): Low limit or less
Transmission output (AO): OFF
Event output: OFF (Contact open) *
* Output still functions during in the Stop state
Output status at STOP mode:
Both event output and Transmission output (AO) are off.
Event output remains unchanged, and Transmission output (AO) is off.
Event output is off, and Transmission output (AO) remains unchanged.
Both Event output and Transmission output (AO) remain unchanged.
STOP display selection: STOP on PV display + STOP lamp (green) lights.
STOP on SV display + STOP lamp (green) lights.
STOP lamp (green) lights.
