10. SPECIFICATIONS
IMR02C15-E4
10-11
Additional function: Hold action: OFF
Hold action ON
(When power turned on; when transferred from STOP to RUN)
Re-hold action ON
(When power turned on; when transferred from STOP to RUN;
SV changed)
• During the operation of the Setting change rate limiter,
Hold action and Re-hold action are not available.
• Hold action is effective for Input value action or
Deviation action.
• Re-hold action is effective for Deviation action.
Event timer: 0 to 600 seconds
Interlock function: Use/Unuse is selectable
Action at input burnout: Action is selectable
îš„ Transmission output (AO) [optional]
Number of outputs: 1 point (Transmission output must be specified for OUT2.)
Output contents: Measured value (PV), Set value (SV), Manipulated output (MV1) [heat-side]
Output type: Voltage output
Output voltage (Rating): 0 to 5 V DC, 1 to 5 V DC, 0 to 10 V DC
Output range: −0.25 to +5.25 V DC, 0.8 to 5.2 V DC,
−0.5 to +10.5 V DC
Allowable load resistance: 1 kΩ or more
Output impedance: 0.1 Ω or less
Current output
Output current (Rating): 0 to 20 mA DC, 4 to 20 mA DC
Output range: 0 to 21 mA DC, 1 to 21 mA DC
Allowable load resistance: 500 Ω or less
Output impedance: 1 MΩ or more
Output scaling: High/Low individual setting
Measured value (PV): Input scale low to Input scale high
Set value (SV): Input scale low to Input scale high
Manipulated output value (MV1) [heat-side]: −5.0 to +105.0 %
AO full scale adjustment value *:
−10.0 to +10.0 %
AO zero adjustment value *:
−10.0 to +10.0 %
* Do not change the factory set adjustment value for the AO full scale adjustment value
and or the AO zero adjustment value as the accuracy will be changed.
