10. SPECIFICATIONS
IMR02C15-E4
10-10
SV high (Using SV monitor value)
SV high (Using local SV)
SV low (Using SV monitor value)
SV low (Using local SV)
Control loop break alarm (LBA)
FAIL
Monitor during RUN
Heater break alarm (HBA)
Output of the communication monitoring result
Setting range: Deviation action:
• Event setting:
High/Low common setting: −Input span to +Input span
Setting a minus (-) value for event types C,
G, T (deviation high/low alarm) and
D (band alarm) is taken as an absolute
value.
• High/Low individual setting: −Input span to +Input span
• Differential gap: 0 to Input span
Process:
• Event setting: Same as input range
• Differential gap: 0 to Input span
SV:
• Event setting: Same as input range
• Differential gap: 0 to Input span
Control loop break alarm (LBA) time:
• LBA time: 0 to 7200 seconds
• LBA deadband (LBD): 0 to Input span
Heater break alarm (HBA):
• Number of HBA: Up to 2 points (1 point per CT input)
• Setting range: 0.0 to 100.0 A *
* 0.0: HBA function OFF
Current value monitoring is still available
• Number of HBA delay time: 0 to 255 times
CT does not detect current value when the event ON time or event
OFF time is 0.5 seconds or less.
Output of the communication monitoring result:
Event signal is turned on when communication is not properly made for 10
seconds.
Event setting and Event differential gap are not available for the
following actions:
Control loop break alarm (LBA), Heater break alarm (HBA), FAIL,
Monitor during RUN, Output of the communication monitoring result
To Next Page
