8. PARAMETER DESCRIPTION
IMR02C15-E4
8-20
Event 1 set value (EV1), Event 1 set value (EV1) [high]
Event 2 set value (EV2), Event 2 set value (EV2) [high]
Event 3 set value (EV3), Event 3 set value (EV3) [high]
Event 4 set value (EV4), Event 4 set value (EV4) [high]
Factory default setting:
The screen is displayed.
Set Event set value. When high/low individual setting is selected for the event
type, the value is the Event set value [high].
Data range Factory set value
Event 1 set value (EV1) to Event 4 set value
(EV4):
Deviation action: −Input span to +Input span
Input value or set value action:
Same as input range
Event 1 set value (EV1) [high] to Event 4 set
value (EV4) [high]:
−Input span to +Input span
TC/RTD inputs: 50 (50.0)
Voltage (V)/Current (I)
inputs: 5.0
Event set value or Event set value [high] is not displayed when the block
selection at F04 [S.F04] (P. 8-70) is set to “1: No display” in the
Engineering mode.
Event set value or Event set value [high] is not displayed when the Event
1 type (ES1) to Event 4 type (ES4) at the Function blocks from F41 to F44
(P. 8-101) are set to “0: No event” in the Engineering mode.
This parameter will not be displayed if Event 1 type (ES1) to Event 4 type
(ES4) (P. 8-101) has been set to “11: Control loop break alarm (LBA), 13:
FAIL, 12: Monitor during RUN, 22: Heater break alarm (HBA) or 23:
Output of the communication monitoring result” in Function block 41
(F41) to 44 (F44) of Engineering mode.
Event 3 and 4 are displayed when 4 points of digital outputs (DO) are
specified. When relay contact output is specified to OUT2 on RB100
PID control, parameter of Event 3 will display.
For the setting of the Event set value, refer to Set the Event set value
(EV) (P. 5-7).
Continued on the next page.
EV1
EV2
EV3
EV4
