8. PARAMETER DESCRIPTION
IMR02C15-E4
8-30
Fine tuning setting
Factory default setting:
The screen is displayed.
Fine tuning function allows the operator to adjust the control response speed
without changing PID values.
Data range Factory set value
−3 to +3
(0: Unused)
0
Positive values quicken the control response while negative values slow
the control response.
Fine tuning setting is not displayed when the block selection at F06
[S.F06] (P. 8-76) is set to “1: No display” in the Engineering mode.
For the Fine tuning function, refer to 6.4 Fine Tuning (P. 6-17).
Related parameters
Engineering mode:
• Fine tuning setting (P. 8-75)
PTU
