8. PARAMETER DESCRIPTION
IMR02C15-E4
8-62
Dummy
F01
F01 block selection (no display)
Hide parameter symbols of the Parameter setting mode from the display.
Data range Factory set value
0: Display
1: No display
1
When “No display” is selected, the parameters of Parameter setting mode
are not displayed; however, F01 parameters are displayed.
For details of setting example, refer to 6.7 Display/No display Setting of
Mode Screens (P. 6-32, P. 6-37).
Related parameter
Parameter setting mode:
• Set value 1 (SV1), Set value 2 (SV2), Set value 3 (SV3), and
Set value 4 (SV4) (P. 8-13)
• SV selection (P. 8-14)
 Description of function
Hide parameters of the Parameter setting mode from the display. Each parameter of Parameter setting
mode link to the Engineering mode from F01 to F10. The parameters of the Parameter setting mode
linked to the parameters of the Engineering mode is not displayed when “No display” is set to F01
block selection. Those parameters of the Parameter setting mode link to F01 block of the Engineering
mode.
S . F01
Parameter of the F01
block linked to the
Parameter setting mode.
Engineering mode
Function block 01 (F01)
Set value 1 (SV1)
Set value 2 (SV2)
Set value 3 (SV3)
Set value 4 (SV4)
SV selection
F01 block selection (no display)
Parameter setting mode
Set value 1 (SV1)
Set value 2 (SV2)
Set value 3 (SV3)
Set value 4 (SV4)
SV selection
Not displayed when set to
“1: No display” in
F01 block selection (no display).
