RKC INSTRUMENT RB Series User Manual

8. PARAMETER DESCRIPTION
IMR02C15-E4
8-76
Dummy
F06
F06 block selection (no display)
Hide parameter symbols of in the Parameter setting mode from the display.
Data range Factory set value
0: Display
1: No display
0
When “No display” is selected, the parameters of Parameter setting mode
are not displayed; however, F06 parameters are displayed.
For details of setting example, refer to 6.7 Display/No display Setting of
Mode Screens (P. 6-32, P. 6-37).
Related parameter
Parameter setting mode:
• Proportional band [heat-side] (P. 8-26)
• Integral time (P. 8-26)
• Derivative time (P. 8-27)
• Anti-reset windup (ARW) (P. 8-27)
• Proportional band [cool-side] (P. 8-28)
• Overlap/Deadband (P. 8-29)
• Fine tuning setting (P. 8-30)
 Description of function
Hide parameters of the Parameter setting mode from the display. Each parameter of Parameter setting
mode link to the Engineering mode from F01 to F10. The parameters of the Parameter setting mode
linked to the parameters of the Engineering mode is not displayed when “No display” is set to F06
block selection. Those parameters of the Parameter setting mode link to F06 block of the Engineering
mode.
S . F06
Engineering mode
Function block 06 (F06)
Proportional band [heat-side]
Integral time
Derivative time
Anti-reset windup (ARW)
Proportional band [cool-side]
Overlap/Deadband
Fine tuning setting
F06 block selection (no display)
Parameter setting mode
Proportional band [heat-side]
Integral time
Derivative time
Anti-reset windup (ARW)
Proportional band [cool-side]
Overlap/Deadband
Fine tuning setting
Parameter of the F06 block linked
to the Parameter setting mode.
Not displayed when set to
“1: No display” in
F06 block selection (no display).
