8. PARAMETER DESCRIPTION
IMR02C15-E4
8-83
Dummy
F08
F08 block selection (no display)
Hide parameter symbols of in the Parameter setting mode from the display.
Data range Factory set value
0: Display
1: No display
0
When “No display” is selected, the parameters of Parameter setting mode
are not displayed; however, F08 parameters are displayed.
For details of setting example, refer to 6.7 Display/No display Setting of
Mode Screens (P. 6-32, P. 6-37).
Related parameter
Parameter setting mode:
• Proportional cycle time [heat-side] (P. 8-36)
• Minimum ON/OFF time of proportioning cycle [heat-side] (P. 8-37)
• Output limiter high [Heat-side output limiter (high)] (P. 8-38)
• Output limiter low [Cool-side output limiter (high)] (P. 8-38)
• Proportional cycle time [cool-side] (P. 8-39)
• Minimum ON/OFF time of proportioning cycle [cool-side] (P. 8-40)
 Description of function
Hide parameters of the Parameter setting mode from the display. Each parameter of Parameter setting
mode link to the Engineering mode from F01 to F10. The parameters of the Parameter setting mode
linked to the parameters of the Engineering mode is not displayed when “No display” is set to F08
block selection. Those parameters of the Parameter setting mode link to F08 block of the Engineering
mode.
S . F08
Engineering mode
Function block 08 (F08)
Proportional cycle time [heat-side]
Minimum ON/OFF time of proportioning cycle [heat-side]
Output limiter high [Heat-side output limiter (high)]
Output limiter low [Cool-side output limiter (high)]
Proportional cycle time [cool-side]
Minimum ON/OFF time of proportioning cycle [cool-side]
F08 block selection (no display)
Parameter setting mode
Proportional cycle time [heat-side]
Minimum ON/OFF time of proportioning cycle [heat-side]
Output limiter high [Heat-side output limiter (high)]
Output limiter low [Cool-side output limiter (high)]
Proportional cycle time [cool-side]
Minimum ON/OFF time of proportioning cycle [cool-side]
Parameter of the F08 block linked to
the Parameter setting mode.
Not displayed when set to
“1: No display” in
F08 block selection (no display).
