8. PARAMETER DESCRIPTION
IMR02C15-E4
8-87
Dummy
F10
F10 block selection (no display)
Hide parameter symbols of in the Parameter setting mode from the display.
Data range Factory set value
0: Display
1: No display
1
When “No display” is selected, the parameters of Parameter setting mode
are not displayed; however, F10 parameters are displayed.
For details of setting example, refer to 6.7 Display/No display Setting of
Mode Screens (P. 6-32, P. 6-37)
Related parameter
Parameter setting mode:
• Manual manipulated output value (MV) (P. 8-42)
Description of function
Hide parameters of the Parameter setting mode from the display. Each parameter of Parameter setting
mode link to the Engineering mode from F01 to F10. The parameters of the Parameter setting mode
linked to the parameters of the Engineering mode is not displayed when “No display” is set to F10
block selection. Those parameters of the Parameter setting mode link to F10 block of the Engineering
mode.
S
.
F10
Parameter setting mode
Not displayed when set to
“1: No display” in
F10 block selection (no display).
Engineering mode
Function block 10 (F10)
Manual manipulated output value (MV)
F10 block selection (no display)
Parameter of the F10 block
linked to the Parameter
setting mode.
Manual manipulated output value (MV)
